Enclosures, Skylight windows

SKYLIGHT WINDOWS WITH MANUAL & POWER OPENING

Thanks to the wide range of measures and available types to adapt to every project, in Disper we supply the appropriate skylight window to provide light to your room.

In addition to providing natural light, its manual or electric opening system gives natural ventilation. They have also been designed to adapt to a wide range of inclination of roofs.

We have pivot opening windows. Top- Pivoting/ Projecting and special lateral or combinable vertical openings as well as a wide range of curtains and accessories that perfectly complement and customize your window according to your preferences and adapting to your decoration.
They are only supplied in standard measures.

Certifications

  • ISO 9001:2000
  • ISO 14001:1996
  • ISO OHSAS 18001:1999
  • Sealed against water air and wind.

Skylux®

FIXED WINDOW FOR FLAT ROOF

Skylux is a fixed flat glass window with an elegant and contemporary design, with an integrated frame in the lower part of the glass, avoids water blockage. It’s provided with double safety glass (4+4 mm and 2 PVB sheets) on the inside and 6 mm tempered glass on the outside with a 24 mm argon gas insulation chamber that provides high thermal and acoustic insulation.
Specially designed for installation on flat roofs with an inclination between 0° and 25°.
It is advised to install it on a roof with a minimum inclination of 5o for a better self-cleaning of the glass.

Easy to install, the Skylux Fixed window is the best solution for providing natural light on horizontal roofs, guaranteeing great thermal and acoustic insulation and total water and wind tightness.
The Skylux Fixed flat roof window can be chosen with an inclined or straight skirting board. The window is available in two versions:
Skylux with inclined base, with the classic pyramidal design.
Skylux with straight base, specially designed to maximize the entry of natural light 100% according to the size of the hole.
Measurement of forged hole = Measurement of light entry. Unique in the market.

zocalo-inclinado
zocalo-recto

CHARACTERISTICS OF THE GLAZING

The elegantly designed safety double glazing with an integrated frame at the bottom prevents water stagnation and guarantees excellent thermal and acoustic insulation and total wind tightness.

HR++ double glazing
Interior glass: 4+4 mm with 2 PVB films (Polyvinyl butyral) Exterior glass: 6 mm tempered
Insulating chamber: 24 mm (with thermal bridge break RPT) Insulating chamber gas: Argon gas
Anti-intrusion resistance level (EN 356):
P2A
Reaction to fire (EN 13501-1): A1

diseno-con-marco-integrado
acristalamiento-1

Skylux® FlexMotor

FIXED WINDOW FOR FLAT ROOF

Skylux Flex Motor is a window with electric flat glass opening with an elegant and contemporary design that can be installed on any type of flat roof. It is the best choice when you need to ventilate.
Depending on the size the flat roof window is opened by 1 or 2 230V chain motors integrated into the frame. The opening is 30 cm using the included remote control, although it can also be connected to a switch/pushbutton.
Between the double glazing and the plinth the window incorporates a PVC frame with EPS with a slope of 4o to avoid water stagnation.

skylux-flex-motor

It includes a rain detector that closes the window automatically in case of rain.
The Skylux Flex Motor flat roof window can be chosen with an inclined base or a straight base.
Specially designed for installation on flat roofs with an inclination between 0o and 21o.
It is not recommended to install in very humid environments such as swimming pools or in places where there is a direct influence with chemical substances.
Easy to install, Skylux Flex Motor windows are the best solution for providing natural light and ventilation in horizontal roofs, guaranteeing great thermal and acoustic insulation and total water and wind tightness.

foto-1

OTHER RANGES

DESIGNO R45

designo-r45

Made of Nordic pine wood, treated with insecticide and water-based fungicide, through a sprinkler system (plow-coat).

A coat of colorless varnish is then applied for conservation.

Admissible slope from 15º to 85º.

Also available in motor version DESIGNO R45 ROTOTONIC.

designo-r45-1
designo-r45-2
designo-r45-3
designo-r45-4

Pivoting-practicable opening. Easy and comfortable to operate. Automatic breaking system

designo-r45-5

Handle on lower crossbar.

designo-r45-6

Sealing gaskets around the frame and in the leaf.

designo-r45-7

Adjustable aeration grille in the upper crosshead.

designo-r45-8

Optional child safety device for easy installation.

DESIGNO 75

designo-r75

Made of Nordic pine wood, treated with insecticide and water-based fungicide, through a sprinkler system (plow-coat).

A coat of colorless varnish is then applied for conservation.

Admissible slope from 20º to 65º.

designo-r75-1
designo-r75-2
designo-r75-3
designo-r75-4

The pivot-projecting opening provides security. The axis of rotation is located in the upper third. It is advisable to place them at medium and low heights.Top quality hardware. Automatic braking system.

designo-r75-5

Handle on lower crossbar.

designo-r75-6

Sealing gaskets around the frame and in the leaf.

designo-r75-7

Adjustable aeration grille in the upper crosshead.

designo-r75-8

Optional child safety device for easy installation.

DESIGNO R45 PVC

designo-r45-pvc

Manufactured in white, reinforced with galvanized steel profiles. Very resistant to impacts.

Admissible slope de 15º to 85º.

The Designo R45 PVC window is ideal for installation in kitchens, bathrooms and especially humid areas.

designo-r45-pvc-1
designo-r45-pvc-2
designo-r45-pvc-3
designo-r45-pvc-4

Pivoting-balancing opening. Easy and comfortable to maneuver. Top quality ironwork. Automatic braking system.

designo-r45-pvc-5

Handle on lower crossbar.

designo-r45-pvc-6

Sealing gaskets around the frame and in the leaf.

designo-r45-pvc-7

Adjustable aeration grille in the upper crosshead.

designo-r45-pvc-8

Optional child safety device for easy installation.

DESIGNO R75 PVC

designo-r75-pvc

Manufactured in white, reinforced with galvanized steel profiles.Very resistant to impacts.

Admissible slope from 20º to 65º.

The Designo R75 PVC window is ideal for installation in kitchens, bathrooms and especially humid areas.

designo-r75-pvc-1
designo-r75-pvc-2
designo-r75-pvc-3
designo-r75-pvc-4

Pivoting-projecting opening. Rotation axis located in the upper third. Top quality hardware. Automatic braking system.

designo-r75-pvc-5

Handle on lower crossbar.

designo-r75-pvc-6

Sealing gaskets around the frame and in the leaf.

designo-r75-pvc-7

Adjustable aeration grille in the upper crosshead.

designo-r75-pvc-8

Optional child safety device for easy installation.

DESIGNO R35 ST

designo-r35-st

Made of Nordic pine wood, treated with insecticide and water-based fungicide, through a sprinkler system (plow-coat).

A coat of colorless varnish is then applied for conservation.

Admissible slope from 20º to 85º.

Side opening.
Telecopic opening system that allows a 90º opening.
Easy and comfortable to maneuver.
Top quality ironworks.

designo-r35-st-1
designo-r35-st-2

Handle on side crossbar.

designo-r35-st-3

Opening system carried out by a pneumatic piston.

designo-r35-st-4

Sealing gaskets around the frame and in the leaf.

designo-r35-st-5

Optional child safety device for easy installation.

ALL OUR WINDOWS CAN HAVE SEVERAL ACCESSORIES THAT COMPLETE THE PERFORMANCE OF ROOF WINDOWS

cortina-resorte

SPRING CURTAIN
100% translucent polyester fabric, facilitates sun protection.
Can be operated remotely using the optional multifunctional opening bar.

cortina-resorte-plus

SPRING PLUS CURTAIN
100% translucent polyester fabric, facilitates sun protection. Can be operated remotely using the optional multifunctional opening bar.

cortina-plisada

PLEATED CURTAIN 100%
Translucent polyester fabric, facilitates sun protection. Can be operated remotely using the optional multifunctional opening bar.

cortina-veneciana

VENETIAN CURTAIN
It doses the entry of light and allows you to play with different luminosities through its adjustable aluminium slats.
Can be operated remotely using the optional multifunctional opening bar.

cortina-oscurecimiento-total

BLACKOUT CURTAIN
Suitable for dormitory rooms. Provides thermal comfort in the hottest seasons.
Can be operated remotely using the optional multifunctional opening bar.

cortina-oscurecimiento-total-decor

TOTAL DECOR BLACKOUT CURTAIN
Suitable for dormitory rooms. Provides thermal comfort in the hottest seasons.
Can be operated remotely using the optional multifunctional opening bar.

persiana-exterior-manual

MANUAL EXTERIOR SHUTTER
The manual exterior shutter is operated from the inside by means of a crank.
The aluminium slats provide a high level of thermal and acoustic insulation.
They provide security and allow the room to be completely darkened.

persiana-exterior-electrica

ELECTRIC EXTERIOR SHUTTER
The electric exterior shutter is operated from the inside by means of a crank.
The aluminium slats provide a high level of thermal and acoustic insulation.
They provide security and allow the room to be completely darkened.

toldo-exterior

OUTSIDE AWNING
The outer awning can be operated from the inside.
The perforated mesh is treated specifically for outdoor use and guarantees optimum sun protection. Also on rainy days it avoids the direct impact of water drops on the glass.

Do you wish for further information about this product?
Extended technical information is at your disposal.
